Xingtai Boshuo Auto Technology Co., Ltd. is one of the leading manufacturers and suppliers of industrial rubber timing belt in China. If you're going to wholesale bulk industrial rubber timing belt made in China, welcome to get pricelist and free sample from our factory. All customized products are with high quality and low price.

Product Description

The Industrial Rubber Timing Belt is a robust power transmission solution engineered for demanding industrial environments, including automated machinery, heavy-duty packaging equipment, and high-capacity conveyor systems. Designed to function as a reliable rubber transmission belt and rubber belt with teeth, it excels in synchronous drive applications where consistent timing and high load-carrying capacity are essential. This high-quality rubber timing belt utilizes a specialized rubber compound and high-strength tensile cords to deliver strong shock absorption, effective wear resistance, and long service life. Available in popular configurations such as the htd 410 5m belt and 3m timing belt, it provides stable, accurate power transfer across a wide range of industrial power transmission belts applications.

Product Structure

This industrial rubber belt is constructed with a three-layer composite design to ensure maximum durability and performance:

Top Rubber Layer: A robust rubber backing that protects the tensile member from external impacts, oil, and heat.
Tensile Member: Embedded high-strength fiberglass or steel cord provides high tensile strength and low stretch, maintaining pitch accuracy under high loads.
Bottom Tooth Rubber: A specially formulated rubber compound that forms the teeth, ensuring flexible and precise engagement with the pulley.
Tooth Fabric: A durable nylon fabric overlay on the tooth surface provides effective friction resistance, extending the product's service life.

Technical Brief

In comparative testing, rubber timing belts with fiberglass tensile cords demonstrate up to 30% lower elongation under 500N load compared to standard fabric-reinforced belts. This ensures stable pitch accuracy over extended maintenance intervals, making them particularly suitable for heavy-duty industrial applications where consistent power transmission is required.

Product Attributes

Product Name	Industrial Rubber Timing Belt
Model	3M,5M,8M,14M,20M; S2M,S3M,S4.5M,S5M,S8M,S14M; RP2M,RP3M,RP5M,RP8M,RP14M; MXL,XXL,XL,L,H,XH,XXH; T2.5,T5,T10,T20,AT5,AT10,AT20
Place of Origin	Hebei, China
Teeth Number	customized
Material	Rubber
Tensile Cord	Steel wire rope/Fiberglass
Color	Black
Features	low noise, heat & oil resistant, high load capacity, shock absorption
Keywords	industrial rubber timing belt, HTD timing belt, synchronous drive belt, rubber toothed belt, power transmission belt
Application Areas	Primarily used in heavy-duty equipment including mining machinery, agricultural harvesters, construction equipment, automotive engines, conveyor systems, and industrial printing presses.
Packaging	carton
MOQ	100pcs
Customization	Support
Certificates	ISO 9001, RoHS
Brand Name	BOSH

Product Parameters

Arc tooth industrial rubber timing belt
Gear code	STPD/STS
Type	S2M	S3M	S4.5M	S5M	S8M	S14M

Picth	2	3	4.5	5	8	14

Tooth height	0.76	1.14	1.71	1.91	3.05	5.3

belt thickness	1.36	1.9	2.81	3.4	5.3	10.2

Gear code	RPP/HPPD
Type	RPP2M	RPP3M	RPP5M	RPP8M	RPP14M

Pitch	2	3	5	8	14

Tooth height	0.76	1.15	1.95	3.2	6

belt thickness	1.36	1.9	3.5	5.5	10

Gear code	HTD
Type	3M	5M	8M	14M	20M

Pitch	3	5	8	14	20

Tooth height	1.17	2.06	3.36	6.02	8.4

belt thickness	2.4	3.8	6	10	13.2

Standard Series – Type & Size
Type	MXL	XXL	XL	L	H	XH	XXH
Picth	2.032	3.175	5.08	9.525	12.7	22.225	31.75
Tooth height	0.51	0.76	1.27	1.91	2.29	6.35	9.53
Belt thinkness	1.14	1.52	3.36	6.02	8.4	11.2	15.7
Type	T2.5	T5	T10	T20	AT5	AT10	AT20
Picth	2.5	5	10	20	5	10	20
Tooth height	0.7	1.2	2.5	5	1.2	2.5	5
Belt thinkness	1.3	2.2	4.5	8	2.7	5	8

Product Specification

Selecting the right rubber timing belt depends on your required power transmission and pulley pitch. Below is our standard XL, L, H, XH, and metric pitch (5M, 8M, 14M) . For custom lengths or tooth profiles, please contact our engineering team.

Type XL
60XL	100XL	126XL	150XL	184XL	216XL	206XL	330XL
66XL	102XL	128XL	152XL	186XL	220XL	266XL	360XL
70XL	104XL	130XL	158XL	188XL	226XL	270XL	364XL
74XL	106XL	132X,	160XL	190XL	228XL	274XL	380XL
76XL	108XL	134XL	164XL	194XL	230XL	280XL
78XL	110XL	136XL	168XL	200XL	236XL	286XL
80XL	114XL	140XL	170XL	204XL	240XL	290XL
86XL	116XL	142XL	172XL	206XL	246XL	300XL
90XL	120XL	144XL	176XL	210XL	248XL	310XL
96XL	122XL	146XL	180XL	212XL	250XL	316XL
98XL	124XL	148XL	182XL	214XL	258XL	320XL
Type L
124L	203L	265L	320L	360L	430L	500L	660L
135L	210L	270L	322L	367L	435L	510L	788L
146L	217L	275L	330L	375L	446L	525L	806L
150L	225L	277L	334L	382L	450L	540L	1091L
160L	230L	280L	337L	390L	453L	560L	1106L
165L	240L	285L	340L	405L	365L	570L
170L	244L	300L	345L	410L	476L	581L
187L	255L	304L	353L	420L	480L	600L
191L	263L	315L	356L	427L	495L	630L
Type H
240H	345H	440H	560H	690H	820H	1100H	1350H
250H	350H	450H	570H	700H	850H	1140H	1360H
260H	360H	460H	580H	710H	860H	1150H	1380H
270H	365H	465H	590H	720H	880H	1170H	1400H
280H	370H	470H	600H	730H	900H	1180H	1450H
290H	375H	480H	610H	740H	925H	1200H	1500H
300H	380H	490H	620H	750H	950H	1225H	1550H
310H	390H	500H	630H	760H	960H	1250H	1600H
315H	400H	510H	640H	770H	975H	1275H	1650H
320H	405H	520H	650H	780H	980H	1300H	1700H
330H	410H	530H	660H	790H	1000H	1310H
335H	420H	540H	670H	800H	1020H	1320H
340H	430H	550H	880H	810H	1050H	1325H
Type XH
490XH	630XH	752XH	820XH	900XH	1300XH	1700XH
506XH	665XH	761XH	840XH	980XH	1400XH
534XH	700XH	770XH	860XH	1000XH	1500XH
570XH	735XH	800XH	875XH	1120XH	1600XH
Type T5
T5-215	T5-265	T5-390	T5-600	T5-1075
T5-220	T5-280	T5-420	T5-690
T5-225	T5-350	T5-500	T5-720
T5-255	T5-355	T5-525	T5-860
Type T5
T10-560	T10-780	T10-920	T10-1200	T10-1420
T10-600	T10-800	T10-980	T10-1210	T10-1610
T10-610	T10-840	T10-1010	T10-1250	T10-1800
T10-700	T10-850	T10-1050	T10-1300	T10-1880
T10-720	T10-880	T10-1100	T10-1320	T10-3300
T10-750	T10-890	T10-1150	T10-1350
Type 5M(HTD)
120-5M	370-5M	525-5M	630-5M	745-5M	890-5M	1140-5M	1490-5M
180-5M	375-5M	530-5M	635-5M	750-5M	900-5M	1145-5M	1500-5M
225-5M	385-5M	535-5M	640-5M	755-5M	920-5M	1175-5M	1540-5M
255-5M	390-5M	540-5M	645-5M	760-5M	925-5M	1200-5M	1595-5M
265-5M	400-5M	545-5M	650-5M	770-5M	930-5M	1210-5M	1650-5M
270-5M	410-5M	550-5M	655-5M	775-5M	940-5M	1225-5M	1690-5M
275-5M	415-5M	560-5M	665-5M	780-5M	950-5M	1235-5M	1700-5M
280-5M	420-5M	565-5M	670-5M	790-5M	960-5M	1250-5M	1750-5M
295-5M	425-5M	570-5M	675-5M	800-5M	975-5M	1270-5M	1760-5M
300-5M	450-5M	575-5M	680-5M	810-5M	980-5M	1280-5M	1800-5M
305-5M	460-5M	580-5M	690-5M	820-5M	985-5M	1320-5M	2000-5M
310-5M	465-5M	585-5M	695-5M	825-5M	1000-5M	1335-5M	2250-5M
320-5M	470-5M	590-5M	700-5M	830-5M	1020-5M	1350-5M	2230-5M
325-5M	475-5M	595-5M	710-5M	835-5M	1025-5M	1355-5M	2400-5M
330-5M	480-5M	600-5M	720-5M	840-5M	1050-5M	1360-5M	2500-5M
340-5M	490-5M	610-5M	725-5M	850-5M	1085-5M	1380-5M
350-5M	500-5M	615-5M	730-5M	860-5M	1100-5M	1400-5M
360-5M	510-5M	620-5M	735-5M	870-5M	1120-5M	1420-5M
365-5M	520-5M	625-5M	740-5M	880-5M	1125-5M	1425-5M
Type 8M(HTD)
312-8M	648-8M	856-8M	1048-8M	1224-8M	1480-8M	1904-8M	2520-8M
344-8M	656-8M	864-8M	1056-8M	1232-8M	1504-8M	1920-8M	2536-8M
352-8M	664-8M	872-8M	1064-8M	1240-8M	1512-8M	1936-8M	2560-8M
376-8M	672-8M	880-8M	1072-8M	1248-8M	1552-8M	1952-8M	2600-8M
392-8M	680-8M	896-8M	1080-8M	1256-8M	1560-8M	1960-8M	2640-8M
400-8M	688-8M	904-8M	1088-8M	1264-8M	1576-8M	2000-8M	2680-8M
440-8M	696-8M	912-8M	1096-8M	1280-8M	1600-8M	2056-8M	2688-8M
480-8M	704-8M	920-8M	1104-8M	1296-8M	1616-8M	2080-8M	2720-8M
496-8M	712-8M	928-8M	1112-8M	1304-8M	1632-8M	2104-8M	2816-8M
512-8M	720-8M	936-8M	1120-8M	1312-8M	1640-8M	2160-8M	2856-8M
544-8M	728-8M	944-8M	1128-8M	1320-8M	1648-8M	2240-8M	2880-8M
560-8M	736-8M	952-8M	1136-8M	1328-8M	1680-8M	2256-8M	2960-8M
568-8M	744-8M	960-8M	1144-8M	1336-8M	1696-8M	2272-8M	3000-8M
576-8M	760-8M	968-8M	1152-8M	1344-8M	1720-8M	2280-8M	3040-8M
584-8M	776-8M	976-8M	1160-8M	1360-8M	1728-8M	2304-8M	3080-8M
592-8M	784-8M	984-8M	1168-8M	1392-8M	1760-8M	2320-8M	3120-8M
600-8M	800-8M	992-8M	1176-8M	1400-8M	1784-8M	2360-8M	3160-8M
608-8M	816-8M	1000-8M	1184-8M	1416-8M	1800-8M	2392-8M	3200-8M
616-8M	824-8M	1008-8M	1192-8M	1424-8M	1824-8M	2400-8M	3800-8M
624-8M	832-8M	1016-8M	1200-8M	1440-8M	1840-8M	2440-8M
632-8M	840-8M	1024-8M	1208-8M	1448-8M	1856-8M	2480-8M
640-8M	848-8M	1040-8M	1216-8M	1456-8M	1896-8M	2504-8M
Type 14M(HTD)
784-14M	1092-14M	1358-14M	1610-14M	1904-14M	2450-14M	2632-14M	2940-14M
826-14M	1120-14M	1400-14M	1680-14M	1960-14M	2492-14M	2660-14M	3010-14M
866-14M	1190-14M	1456-14M	1764-14M	2100-14M	2520-14M	2730-14M	3080-14M
1050-14M	1260-14M	1512-14M	1778-14M	2310-14M	2548-14M	2800-14M	3150-14M
1064-14M	1344-14M	1540-14M	1890-14M	2380-14M	2590-14M	2870-14M

Type RPP5M(HPPD/RPP)
255-RPP5M	305-RPP5M	340-RPP5M	510-RPP5M	615-RPP5M	645-RPP5M
280-RPP5M	325-RPP5M	365-RPP5M	520-RPP5M	625-RPP5M	655-RPP5M
300-RPP5M	330-RPP5M	465-RPP5M	530-RPP5M	640-RPP5M	670-RPP5M
985-RPP5M	1000-RPP5M
Type RPP8M(HPPD/RPP)
352-RPP8M	440-RPP8M	760-RPP8M	800-RPP8M	1006-RPP8M	1046-RPP8M
376-RPP8M	640-RPP8M	776-RPP8M	896-RPP8M	1016-RPP8M	1232-RPP8M
400-RPP8M	680-RPP8M	784-RPP8M	984-RPP8M	1024-RPP8M	1224-RPP8M
1400-RPP8M	1456-RPP8M
Type RPP14M(HPPD/RPP)
784-RPP14M	1064-RPP14M	1358-RPP14M	1540-RPP14M	1764-RPP14M	1960-RPP14M
726-RPP14M	1109-RPP14M	1400-RPP14M	1610-RPP14M	1890-RPP14M	2100-RPP14M
966-RPP14M	1344-RPP14M	1456-RPP14M	1680-RPP14M	1904-RPP14M	2380-RPP14M

Product Profile Size 1
