Xingtai Boshuo Auto Technology Co., Ltd. is one of the leading manufacturers and suppliers of double sided v ribbed belt in China. If you're going to wholesale bulk double sided v ribbed belt made in China, welcome to get pricelist and free sample from our factory. All customized products are with high quality and low price.
Product Description
The Double Sided V Ribbed Belt is designed for applications where the belt must drive components from both sides, such as serpentine engine layouts and industrial machinery. This Double Sided V Ribbed Belt provides reliable power transmission for both conventional and reverse bend drives. It works effectively as Serpentine Belts in modern engines and also serves as a Fan Ribbed Belt or fan v belt for cooling systems. Available options include 3 rib belt, 4 rib serpentine belt, and 6 rib belt, allowing you to match different pulley widths and load requirements. Made from high quality rubber with strong polyester cord, it offers low stretch, heat resistance, and stable performance under continuous operation.
Product Characteristics
- Double sided ribs, can drive pulleys on both sides
- Transmission efficiency up to 95% or higher
- Low noise, low vibration operation
- Good flexibility, suitable for small diameter pulleys
- EPDM material, temperature range -40°C to +150°C
- High strength cord, low elongation
- Suitable for automotive, industrial, household appliances and other fields
|
Type |
Pb |
Height |
length (inch) |
length (mm) |
Angle |
|
PK |
3.56 |
6 |
22一120 |
559一3048 |
40° |
|
PJ |
2.34 |
4 |
13一120 |
330一3048 |
40° |
|
PH |
1.6 |
3 |
21一120 |
540一3048 |
40° |
|
PL |
4.7 |
10 |
20一160 |
900一4064 |
40° |
Product Specifications
Type:PK Rib Number :3-20pk Length (mm):800mm-3000mm Support customization
|
PK800 |
PK910 |
PK1040 |
PK1225 |
PK1395 |
PK1650 |
PK1780 |
PK2040 |
PK2305 |
PK2710 |
|
PK805 |
PK915 |
PK1045 |
PK1235 |
PK1405 |
PK1610 |
PK1790 |
PK2050 |
PK2320 |
PK2720 |
|
PK810 |
PK920 |
PK1055 |
PK1245 |
PK1410 |
PK1615 |
PK1795 |
PK2055 |
PK2340 |
PK2730 |
|
PK815 |
PK930 |
PK1065 |
PK1250 |
PK1415 |
PK1620 |
PK1800 |
PK2065 |
PK2350 |
PK2750 |
|
PK820 |
PK935 |
PK1070 |
PK1265 |
PK1420 |
PK1630 |
PK1815 |
PK2080 |
PK2365 |
PK2760 |
|
PK825 |
PK945 |
PK1085 |
PK1270 |
PK1435 |
PK1640 |
PK1820 |
PK2090 |
PK2370 |
PK2770 |
|
PK830 |
PK950 |
PK1090 |
PK1275 |
PK1450 |
PK1655 |
PK1830 |
PK2100 |
PK2375 |
PK2780 |
|
PK835 |
PK960 |
PK1105 |
PK1280 |
PK1460 |
PK1660 |
PK1845 |
PK2110 |
PK2400 |
PK2800 |
|
PK840 |
PK965 |
PK1110 |
PK1295 |
PK1470 |
PK1665 |
PK1850 |
PK2120 |
PK2415 |
PK2820 |
|
PK850 |
PK970 |
PK1120 |
PK1300 |
PK1485 |
PK1680 |
PK1860 |
PK2130 |
PK2430 |
PK2830 |
|
PK855 |
PK975 |
PK1135 |
PK1310 |
PK1495 |
PK1695 |
PK1870 |
PK2138 |
PK2450 |
PK2850 |
|
PK860 |
PK980 |
PK1145 |
PK1325 |
PK1505 |
PK1700 |
PK1890 |
PK2150 |
PK2460 |
PK2870 |
|
PK865 |
PK985 |
PK1150 |
PK1330 |
PK1520 |
PK1705 |
PK1900 |
PK2175 |
PK2470 |
PK2890 |
|
PK870 |
PK990 |
PK1165 |
PK1335 |
PK1525 |
PK1710 |
PK1920 |
PK2200 |
PK2475 |
PK2900 |
|
PK875 |
PK995 |
PK1175 |
PK1346 |
PK1530 |
PK1720 |
PK1925 |
PK2235 |
PK2490 |
PK2920 |
|
PK885 |
PK1000 |
PK1185 |
PK1350 |
PK1555 |
PK1730 |
PK1940 |
PK2255 |
PK2520 |
PK2930 |
|
PK890 |
PK1010 |
PK1190 |
PK1355 |
PK1560 |
PK1745 |
PK1945 |
PK2260 |
PK2550 |
PK2950 |
|
PK895 |
PK1020 |
PK1205 |
PK1365 |
PK1570 |
PK1750 |
PK1970 |
PK2270 |
PK2580 |
PK2960 |
|
PK900 |
PK1025 |
PK1215 |
PK1375 |
PK1585 |
PK1765 |
PK1980 |
PK2285 |
PK2600 |
PK2990 |
|
PK905 |
PK1035 |
PK1220 |
PK1390 |
PK1595 |
PK1770 |
PK2000 |
PK2300 |
PK2700 |
PK3000 |
Product Attributes
|
Product Name |
Double Sided Multi Rib Belt |
Tensile Cord |
High Strength Polyester / Aramid Cord |
|
Length Range |
800mm - 3000mm |
Pitch |
3.56mm |
|
Model |
DPK (Double PK Belt) |
Groove Angle |
40° |
|
Material |
EPDM / CR Rubber |
Packing |
Carton |
|
Customization |
Support |
MOQ |
100PCS |
|
Standard or Nonstandard |
Nonstandard |
Place of Origin |
Hebei, China |
|
Brand Name |
Customization |
Color |
Black |
|
Temperature Range |
-40°C to +150°C (EPDM) / -30°C to +100°C (CR) |
Certificates |
ISO 9001, RoHS |
|
Application |
Automotive serpentine drive, industrial machinery, household appliances, agricultural equipment, construction machinery |
Lead Time |
20-30 days |
Our Shipping
Our products have been exported to more than 80 countries across Asia, Africa, Europe, South America, and the Middle East. From heavy duty trucks in Saudi Arabia to harvesters in Brazil, from construction machinery in Indonesia to auto repair shops in Nigeria – Boshuo belts keep industries moving.
FAQ
Q1: Can we stencil (or print ) our logo or company name on the belt or package?
---- Yes. Please inform us your logo or design before mass production.
Q2: What is your payment term?
---- T/T 30% deposit and T/T 70% balance before shipment.
Q3: What is your quotation?
---- We will give you FOB price. But EXW, CIF and CNF can also be given according to your demands.
