MOQ: | |
---|---|
Material: | |
Availability: | |
Quantity: | |
97RU25
Boshuo
PRODUCT FEATURES
Automotive timing belt uses CR or HNBR as main rubber material, produced strictly according to technical standard. The belt has the feature of perfect tooth shape, long service life, less noise, high force of driving, better driving precision, better wearable performance.
Structure
NO | Name | Function | Material |
1 | Top Rubber | Protect the lining tensile member | CR |
2 | Tensile Member | Protect the tensile member and maintain the shape of the rubber, prevent the rubber from stretching | Glass Fiber |
3 | Teeth Rubber | Protect the tensile member and maintain the shape of the rubber | CR |
4 | Teeth Fabric | Excellent frictional resistance which prolongs the service l-ife of product | Nyion Fabric |
FEATURES
Low noise operation
No lubrication needed
Prevent skidding
Conservation of fuel and good economy
Super-high mechanical efficiency
Section Size Of Sychronous Belt For Automobile
Profile | Diamension | Profile | |||
P | hs | t | ht | ||
MR | 9.525 | 5.70 | 2.20±0.25 | 3.40 | Round tooth |
RU | 9.522 | 5.41 | 2.00±0.25 | 3.41 | Round tooth |
YU | 8.000 | 5.30 | 2.25±0.25 | 3.05 | Trap ezoidal tooth |
ZA | 9.525 | 4.21 | 2.30±0.25 | 1.91 | Trap ezoidal tooth |
ZBS | 9.525 | 5.06 | 2.30±0.25 | 2.60 | Trap ezoidal tooth |
S8M | 8.000 | 5.30 | 2.25±0.25 | 2.90 | Trap ezoidal tooth |
MY | 8.000 | 5.21 | 2.15±0.25 | 3.06 | Round tooth |
ZB | 9.525 | 5.50 | 2.21±0.25 | 2.29 | Trap ezoidal tooth |
If you hava special requirements, Please contact us and we will try to satisfy your needs.
OVERVIEW
PRODUCT PACKAGING
FACTOR TOUR
CERTIFICATE
EXHIBITION
MODE OF TRANSPORT
To be negotiated :
Quantity(Piece) | 1-1000 | >1000 |
Est. Time(days) | 15 | To be negotiated |
RFQ
Q1: Can i order a small quantity of samples?
---- Yes. We can offer you samples at the bulk prices and send them by DHL, TNT. EMS, FEDEX
or others according to your requirements.
Q2: How could i know whether the belt fits for my machine?
---- You can tell me which product you are interested in, and i will give you its main sizes. You
can also send me drawings or samples, and then we will put them into production at your requests.
Q3: I want to find a supplier for my new products. Can you help me?
---- Yes. Kindly offer me your drawings or samples for analysis.
Q4: How long does it take to make a new product?
---- Usually 10-15 days for drawings and 7 days for samples.
Q5: Can we stencil (or print ) our logo or company name on the belt or package?
---- Yes. But we have a minimum order quantity.
Q6: What is your payment term?
---- T/T 30% deposit and T/T 70% balance beforce shipment.
Q7: What is your quotation?
---- We will give you FOB price. But EXW, CIF and CNF can also be given according to your demands.
APPLICATION SCENARIOS
